    960mm Metal Roof Forming Machine , Galvanized Sheet Metal Forming Equipment

    Ask Lasest Price
    Certification : BV,SGS, CE,ISO9001
    Payment Terms : L/C, T/T
    Supply Ability : 30 SETS / MONTH
    Delivery Time : 20 Working days
    Price : Negotiation
    • Product Details
    • Company Profile

    960mm Metal Roof Forming Machine , Galvanized Sheet Metal Forming Equipment

    EPS Sandwich Wall Panel Machine / Precast Concrete Lightweight Wall Panel Machine


    Botou Aluminum Wall Panel EPS Cement Sandwich Production Line

    Sandwich panel sample

    960mm Metal Roof Forming Machine , Galvanized Sheet Metal Forming Equipment

    960mm Metal Roof Forming Machine , Galvanized Sheet Metal Forming Equipment

    All the sheet sizes could design according to customers's requirments!


    Machine parameter

    Panel thicknessEPS30-300mm
    Rockwool40-150mm
    Painted steel
    Thickness of painted steel0.3-0.8mm
    Max width of painted steel
    Max coil weightAbout 5T
    Inside diameter of coil480-520mm
    Roll former
    Station13
    Roller diameter70mm
    Material of roller45# steel heat treatment, 0.05-0.07mm chroming
    Type of synchroniesElectrical synchronies
    Driven power3kw
    SizeAbout 9600*2000*1640mm
    WeightAbout 8T
    Sandwich panel machine
    UncoilerSemi-auto
    Type of shearingelectrical
    Numbers of shearing2 sets
    Glue pump4 sets (2 upper, 2 lower)
    Flow volume glue
    Roller diameter150mm
    Whole line dimensionAbout 47000*3100*2200mm
    Total weight12T
    Working speedAbout 0-5m/min
    The output1500-2000SQM/8 hour
    Control modePLC and converter
    Total powerAbout 35kw(as per final design )
    Cutter
    Stroke of cutter1800mm cylinder distance
    ControlPLC and touch screen(DELTA)
    WeightAbout 1.5T
    Scrap recycling device
    CollectingVacuum
    Driven power2.2kw

    Machine shows

    960mm Metal Roof Forming Machine , Galvanized Sheet Metal Forming Equipment

    960mm Metal Roof Forming Machine , Galvanized Sheet Metal Forming Equipment960mm Metal Roof Forming Machine , Galvanized Sheet Metal Forming Equipment

    960mm Metal Roof Forming Machine , Galvanized Sheet Metal Forming Equipment

    FAQ

    Q: Can you make the product according to my design or proto type?
    A: Yes. We have an experienced team for working out the most suitable design and production plan for the machine that you are going to book with us

    Q: Are you a factory or trading company ?

    A: We are a factory?

    Q: Where is your factory located?

    A: Our factory is located in YingKou City, LiaoNing Province, China. All our clients, from home or abroad, are warmly welcome to visit us !

    Q: How do you guarantee the quality of the products?

    A: Strict product quality, unqualified resolute don't factory.This is the tenet of our factory

    Every one of our products have strict testing procedures, must be 100% quality assurance

    Service

    We provide the technical support for whole life.

    Meanwhile, if any parts go broken and not artificial damage, we will send you new ones for free.

    When need the technician to go abroad, we will arrange the technician.

    But the buyer should take all the cost, including Visa, Roundtrip ticket,

    suitable accommodation and pay the service fee to the technician with $100/days

    Payment

    T/T( 30% by T/T in advance, the rest 70% to be paid by T/T after you inspect the machine

    in seller's factory before delivery )
